Manufacturer of straight asphalt bitumen grade 160/220

Home » Iran bitumen manufacturer » Manufacturer of straight asphalt bitumen grade 160/220

General description of bitumen 160/220

ADTM bitumen penetration grade 160/220 is hard penetration grade bitumen using as paving grade bitumen suitable for road construction and repair also for the production of asphalt pavements with below technical specification. This grade of bitumen is mainly used in the manufacture of hot mix asphalt for bases and wearing courses.

Softening point and penetration of  the bitumen

Penetration grade bitumen supplied by ATDM is pure petroleum grade bitumen, manufactured from vacuum bottom by passing hot air. The bitumen supplied by ATDM is produced from remain of crude oil after cracking and removing hydrocarbon. It has penetration between 160~220 desi-millimeter and softening point between 35~ 43C. The penetration grade of the bitumen has a thermoplastic property which is like as synthetic resin material which gets softer with heating and hardens when cooled. This grade has very strong viscosity compare to other grades.

Guaranty/warranty of bitumen

ATDM guaranty the quality of  160/220 with arrangement of international inspector to check quality and quantity of the bitumen during the loading to vessel and controlling the production by QC by batch test report before shipping. ATDM guaranty the quality to meet with ASTM/EN 12591,standard ensuring customer confidence and satisfaction.

Specification of penetration bitumen

 160/220

Specification

Test method

Specific gravity @ 25/25 cg

1.01/1.06

D-70

Penetration @ 25 c

220/160

D-5

Softening point c

35/43

D-36

Ductility @25 c

100 min

D113

Loss on heating(wt) %

0.2 Max

D-6

Drop in penetration after heating %

20 Max

D-6 D-5

Flash point c

250 min

D-92

Solubility is CS2(wt) %

99.5 Max

D-4

Spot test

negative

A.A.S.H.O.T102



 Specification of  Bitumen 160/220

 MSDS of  Bitumen 160/220

MSDS -160/220
