Bitumen 15/25 useful for paving of bridge

Home » Bitumen 15/25 useful for paving of bridge

bitumen-15-25

Bitumen 15/25

Bitumen 15/25 is penetration bitumen which is blown by hot air and blended by special polymers to keep the penetration in low level and softening point in high level.

Why contractor choose this grade?

Selection of the appropriate binder is a very important aspect in the asphalt mix design process. Usually binder grades are affected by temperature and traffic loading expected in service, with stiffer binder grades selected when heavily loaded or slow-moving vehicles are expected. However, utilisation of stiffer binders often results in stiff mixes that have workability related issues since they are not easy to place and compact to the desired density. Furthermore, sometimes stiff binders are modified with polymers that further increase their viscosity hence substantially negatively impacting on workability at a given temperature.

Application of bitumen 15/25

This type of the Bitumen  useful for paving of bridge and stiffness asphalt mixes in heavy traffic road construction.

It is used in bituminous mixtures and gives it a high degree of stiffness, developing a good tensile strength and fatigue specifically, according to the pg-3 standard, a high modulus for semi-dense mixtures man means a stiffness modulus> 1 1000 MPA.

Properties & specifications

It is meets the NEN EN 13924:2006 specification requirements

Resistance to hardening: rolling thin film oven test at 163 °c (en 12607-1)

The NEN en 13924 specifications may be subject to change.

Bitumen 15/25 grade delivered to worldwide market as per en 13924 specifications.

Specification and analysis

Item

Specification

Test method

Specific gravity @ 25/25 cg

1.01/1.06

D-70

Penetration @ 25 c

25/15

D-5

Softening point c

60/76

D-36

Ductility @25 c

100 min

D-113

Loss on heating(wt) %

0.2 Max

D-6

Drop in penetration after heating %

20 Max

D-6 D-5

Flash point c

250 min

D-92

Solubility is CS2(wt) %

99.5 Max

D-4

Spot test

negative

A.A.S.H.O.T102

Specification of Bitumen

15/25

TDS of Bitumen 15/25



MSDS of bitumen 15/25
